| | 品牌：华强牌 | | 型号：ZR-YC 3*185，ZR-YC 3*185 | | 线芯材质：铜丝 | |
| | 电压等级：中.低压电力电缆（35千伏及以下） | | 绝缘材料：橡皮绝缘电力电缆 | | 芯数：3芯 | |
| | 护套材质：橡胶 | | 电线*大外径：55 mm | | 绝缘厚度：2.0 mm | |
| | 标称截面：185 mm2 | | 用途：橡胶电力电缆 | | | |
ZR-YC 3*185，ZR-YC 3*185品用途：本产品适用于交流额定电压0.6/1V及以下家用电器,电动工具和各种移动多电器设备电缆的长期工作温度应不超过65℃ “W”型派电缆具有耐气候和一定的耐油性能,适用于在户外接触油污场合使用。
电缆型号
| 型号 |
名称 |
用途 |
| YC、YCW |
重型橡套软电缆 |
用于各种移动电器设备，能承受较大的机械外力作用 |
ZR-YC 3*185电缆结构技术性能：电缆绝缘线芯间的绝缘电阻换算到温度20℃时应：
35mm2及以下者…不小于50MΩ·Km
50-150mm2及以下者…不小于30MΩ·Km
185-240mm2及以下者…不小于20MΩ·Km标称截面435mm2及以下规格的电缆应能经受曲挠试验，经往复曲挠1500次试验后，试样应不发生电流的断路，并能受交流50HZ 2000V电压试验5min。
YC、YCW型电缆绝缘线芯间应经受交流50HZ 2500V电压试验5min.
ZR-YC 3*185电缆的导电线芯结构及电阻
| 标称截面mm2 |
结构 |
20℃导体直流阻Ω/km |
标称截面mm2 |
结构 |
20℃导体直流阻Ω/km |
| 0.3 |
16/0.15 |
≤69.2 |
16 |
126/0.40 |
≤1.21 |
| 0.5 |
28/0.15 |
≤39.0 |
25 |
196/0.40 |
≤0.780 |
| 0.75 |
24/0.20 |
≤26.0 |
35 |
276/0.40 |
≤0.554 |
| 1.0 |
32/0.20 |
≤19.5 |
50 |
396/0.40 |
≤0.386 |
| 1.5 |
30/0.25 |
≤13.3 |
70 |
360/0.50 |
≤0.272 |
| 2.5 |
49/0.25 |
≤7.98 |
95 |
475/0.50 |
≤0.206 |
| 4 |
56/0.30 |
≤4.95 |
120 |
608/0.50 |
≤0.161 |
| 6 |
84/0.30 |
≤3.30 |
150 |
756/0.50 |
≤0.129 |
| 10 |
84/0.40 |
≤1.91 |
|
|
|
YC YCW重型橡套软电缆
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 1×1.5 |
5.6 |
7.2 |
55 |
57.0 |
13.3 |
13.7 |
20 |
| 1×2.5 |
6.4 |
8.0 |
73.7 |
79.5 |
7.98 |
8.21 |
27 |
| 1×4 |
7.2 |
9.0 |
110.5 |
118.7 |
4.95 |
5.09 |
36 |
| 1×6 |
8.0 |
11.0 |
135 |
167.3 |
3.30 |
3.39 |
47 |
| 1×10 |
9.8 |
13.0 |
220.6 |
234.8 |
1.91 |
1.95 |
65 |
| 1×16 |
11.0 |
14.5 |
295.1 |
311.6 |
1.21 |
1.24 |
85 |
| 1×25 |
12.5 |
16.5 |
425.6 |
446.2 |
0.780 |
1.79 |
115 |
| 1×35 |
14.0 |
18.5 |
561.9 |
587.5 |
0.554 |
0.565 |
145 |
| 1×50 |
16.5 |
21.0 |
758.4 |
788.4 |
0.386 |
0.393 |
175 |
| 1×70 |
18.5 |
4.0 |
1034.1 |
1073.7 |
0.272 |
0.277 |
220 |
| 1×90 |
21.0 |
26.0 |
1324.7 |
1369.3 |
0.206 |
0.210 |
265 |
| 1×120 |
23.0 |
28.5 |
1598.9 |
1646.3 |
0.161 |
0.164 |
310 |
| 1×150 |
25.0 |
32.0 |
1974.6 |
2108 |
0.129 |
0.132 |
360 |
| 1×185 |
27.5 |
34.5 |
2540 |
2498 |
0.106 |
0.108 |
410 |
| 2×1.5 |
9.0 |
11.5 |
132 |
146.6 |
13.3 |
13.7 |
16 |
| 2×2.5 |
10.5 |
13.5 |
203.6 |
223.9 |
7.98 |
8.21 |
23 |
| 2×4 |
12.0 |
15.0 |
280.2 |
305.6 |
4.95 |
5.09 |
30 |
| 2×6 |
13.5 |
18.0 |
412.2 |
448.20 |
3.30 |
3.39 |
39 |
| 2×10 |
18.5 |
24.0 |
669.1 |
732.8 |
1.91 |
1.95 |
55 |
| 2×16 |
21.0 |
27.5 |
906.6 |
988.5 |
1.21 |
1.24 |
73 |
| 2×25 |
24.5 |
31.5 |
1144.3 |
1321 |
0.780 |
0.795 |
96 |
| 3×1.5 |
9.6 |
12.5 |
164 |
1890 |
13.3 |
13.7 |
14 |
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 5×10 |
4.0 |
31.0 |
1205.2 |
1289.0 |
1.91 |
1.95 |
40 |
| 5×16 |
27.0 |
35.5 |
1668.8 |
1777.0 |
1.21 |
1.24 |
53 |
| 5×25 |
32.5 |
41.5 |
2434.3 |
2578.1 |
0.780 |
0.795 |
70 |
3+1芯
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 3×1.5+1×1 |
9.4 |
12.0 |
--- |
--- |
13.3 |
13.7 |
14 |
| 3×2.5+1×1.5 |
11.0 |
14.0 |
282.7 |
305.6 |
7.98 |
8.21 |
19 |
| 3×4+1×2.5 |
13.0 |
16.0 |
406.8 |
435.7 |
4.95 |
5.09 |
26 |
| 3×6+1×4 |
14.5 |
19.5 |
600.1 |
640.34 |
3.30 |
3.39 |
33 |
| 3×10+1×6 |
20.5 |
26.5 |
925.1 |
990.9 |
1.91 |
1.95 |
47 |
| 3×16+1×6 |
23.0 |
26.5 |
1253.9 |
1341.5 |
1.91 |
1.95 |
62 |
| 3×16+1×10 |
23.0 |
30.0 |
--- |
--- |
1.21 |
1.24 |
63 |
| 3×25+1×10 |
28 |
35.5 |
1823.2 |
1941.5 |
0.780 |
0.795 |
83 |
| 3×35+1×10 |
30.0 |
38.5 |
1980.4 |
244.7 |
0.554 |
0.565 |
100 |
| 3×50+1×16 |
36.0 |
46.0 |
3952 |
3439.7 |
0.368 |
0.393 |
125 |
| 3×70+1×25 |
40.0 |
51.0 |
4504.4 |
4772.6 |
0.272 |
0.277 |
--- |
| 3×95+1×35 |
46.5 |
59.0 |
5972 |
6346 |
0.206 |
0.210 |
--- |
| 3×120+1×35 |
46.5 |
59.0 |
6362.1 |
6662.4 |
0.161 |
0.164 |
--- |
| 3×150+1×50 |
52.0 |
66.0 |
7889.3 |
8252.6 |
0.129 |
0.132 |
--- |
3+2芯
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 3×4+2×2.5 |
14.3 |
17.8 |
399 |
415 |
4.95 |
5.09 |
26 |
| 3×6+2×4 |
19.5 |
23.0 |
607 |
631 |
3.30 |
3.39 |
33 |
| 3×10+2×6 |
23.0 |
26.0 |
914 |
947 |
1.91 |
1.95 |
47 |
| 3×16+2×6 |
28.5 |
33.5 |
1194 |
1235 |
1.21 |
1.24 |
62 |
| 3×25+2×10 |
30.0 |
35.0 |
1697 |
1762 |
0.780 |
0.795 |
83 |
| 3×35+×10 |
36.0 |
41.0 |
2275 |
2350 |
0.554 |
0.565 |
100 |
| 3×50+2×16 |
40.0 |
45.0 |
3074 |
3117 |
0.386 |
0.393 |
125 |
| 3×50+2×25 |
42.5 |
45.5 |
3454 |
3564 |
|
|
|
| 3×70+2×25 |
44.0 |
50.0 |
4165 |
4285 |
0.272 |
0.272 |
--- |
| 3×95+2×35 |
46.0 |
52.5 |
5552 |
5270 |
0.206 |
0.10 |
--- |
| 3×120+2×35 |
52.0 |
58.0 |
6405 |
6550 |
0.161 |
0.164 |
--- |
| 3×150+2×50 |
61.0 |
67.0 |
8065 |
8376 |
0.129 |
0.132 |
--- |
| 3×185+2×50 |
78.0 |
86.0 |
9538 |
9891 |
0.106 |
0.108 |
--- |
| 3×240+2×70 |
81.0 |
89.0 |
12083 |
12580 |
0.0801 |
0.0817 |
--- |
