| | 加工定制：是 | | 型号：KVVRP-450/750V 7*2.5 | | 品牌：华强牌 | |
| | 护套材质：PVC | | 线芯材质：铜丝 | | 芯数：7芯 | |
| | 材料形状：圆线 | | 拉伸强度：30 | | 电线*大外径：12 mm | |
| | 绝缘厚度：1.20 mm | | 产品认证：国家认证 | | | |
KVVRP-450/750V 7*2.5控制屏蔽软电缆使用特性
交流额定电压：450/750V
*高工作温度：聚氯乙烯(聚乙烯)绝缘不超过70度；交联聚乙烯绝缘90度
*低环境温度：聚氯乙烯护套：固定敷设-40℃，非固定敷设-15℃
电缆安装敷设温度应不低于0℃。
允许弯曲半径：非铠装电缆*小为电缆外径的6倍；铜带屏蔽或钢带铠装电缆*小为电缆外径的12倍。
KVVRP-450/750V 7*2.5电缆
| 序号 |
芯数×标称
截面(mm2) |
导体种类
上限 |
外径(mm) |
70℃*小绝缘
电阻(MΩ．Km) |
序号 |
芯数×标称
截面(mm2) |
导体种类 |
外径mm上限 |
70℃*小绝缘
电阻(MΩ．Km) |
| 1 |
2×0.75 |
1 |
8.0 |
0.012 |
32 |
4×1.5 |
2 |
11.5 |
0.010 |
| 2 |
2×0.75 |
2 |
8.4 |
0.014 |
33 |
4×2.5 |
1 |
12.0 |
0.010 |
| 3 |
2×1.0 |
1 |
8.4 |
0.011 |
34 |
4×2.5 |
2 |
13.0 |
0.009 |
| 4 |
2×1.0 |
2 |
8.8 |
0.013 |
35 |
4×4 |
1 |
14.0 |
0.0085 |
| 5 |
2×1.5 |
1 |
9.4 |
0.011 |
36 |
4×4 |
3 |
15.0 |
0.0077 |
| 6 |
2×1.5 |
2 |
10.0 |
0.010 |
37 |
4×6 |
1 |
15.0 |
0.0070 |
| 7 |
2×2.5 |
1 |
10.5 |
0.010 |
38 |
4×6 |
2 |
16.5 |
0.0065 |
| 8 |
2×2.5 |
2 |
11.5 |
0.009 |
39 |
4×10 |
2 |
20.0 |
0.0065 |
| 9 |
2×4 |
1 |
11.5 |
0.0085 |
40 |
5×0.75 |
1 |
9.6 |
0.013 |
| 10 |
2×4 |
2 |
12.5 |
0.0070 |
41 |
5×0.75 |
2 |
10.5 |
0.014 |
| 11 |
2×6 |
1 |
12.5 |
0.0070 |
42 |
5×1.0 |
1 |
10.0 |
0.011 |
| 12 |
2×6 |
2 |
14.0 |
0.0065 |
43 |
5×1.0 |
2 |
11.0 |
0.013 |
| 13 |
2×10 |
2 |
17.5 |
0.0065 |
44 |
5×1.5 |
1 |
11.5 |
0.011 |
| 14 |
3×0.75 |
1 |
8.4 |
0.012 |
45 |
5×1.5 |
2 |
12.5 |
0.010 |
| 15 |
3×0.75 |
2 |
8.8 |
0.014 |
46 |
5×2.5 |
1 |
14.0 |
0.010 |
| 16 |
3×1.0 |
1 |
8.8 |
0.011 |
47 |
5×2.5 |
2 |
14.5 |
0.009 |
| 17 |
3×1.0 |
2 |
9.2 |
0.013 |
48 |
5×4 |
1 |
15.0 |
0.0085 |
| 18 |
3×1.5 |
1 |
9.8 |
0.011 |
49 |
5×4 |
2 |
16.5 |
0.0077 |
| 19 |
3×1.5 |
2 |
10.5 |
0.010 |
50 |
5×6 |
1 |
16.5 |
0.0070 |
| 20 |
3×3.5 |
1 |
11.0 |
0.010 |
51 |
5×6 |
2 |
18.0 |
0.0065 |
| 21 |
3×2.5 |
2 |
12.0 |
0.009 |
52 |
5×10 |
2 |
22.5 |
0.0065 |
| 22 |
3×4 |
1 |
12.5 |
0.0085 |
53 |
7×0.75 |
1 |
10.5 |
0.012 |
| 23 |
3×4 |
2 |
13.5 |
0.0077 |
54 |
7×0.75 |
2 |
11.0 |
0.014 |
| 24 |
3×6 |
1 |
14.0 |
0.0070 |
55 |
7×1.0 |
1 |
11.0 |
0.011 |
| 25 |
3×6 |
2 |
15.0 |
0.0065 |
56 |
7×1.0 |
2 |
11.5 |
0.013 |
| 26 |
3×10 |
2 |
18.5 |
0.0065 |
57 |
7×1.5 |
1 |
12.5 |
0.011 |
| 27 |
4×0.75 |
1 |
9.0 |
0.012 |
58 |
7×1.5 |
2 |
13.5 |
0.010 |
| 28 |
4×0.75 |
2 |
9.6 |
0.014 |
59 |
7×2.5 |
1 |
15.0 |
0.010 |
| 29 |
4×1.0 |
1 |
9.4 |
0.011 |
60 |
7×2.5 |
2 |
16.0 |
0.009 |
| 30 |
4×1.0 |
2 |
10.0 |
0.013 |
61 |
7×4 |
1 |
16.5 |
0.0085 |
| 31 |
4×1.5 |
1 |
10.5 |
0.011 |
62 |
7×4 |
2 |
17.5 |
0.0077 |
| 型号 |
产品名称 |
| KVV |
铜芯聚氯乙烯绝缘聚氯乙烯护套控制电缆 |
| KVVP |
铜芯聚氯乙烯绝缘聚氯乙烯护套铜丝编织屏蔽控制电缆 |
| KVVP2 |
铜芯聚氯乙烯绝缘聚氯乙烯护套铜带屏蔽控制电缆 |
| KVV22 |
铜芯聚氯乙烯绝缘聚氯乙烯护套钢带铠装控制电缆 |
| KVVR |
铜芯聚氯乙烯绝缘聚氯乙烯护套控制软电缆 |
| KVVRP |
铜芯聚氯乙烯绝缘聚氯乙烯护套铜丝编织屏蔽控制软电缆 |
| KVVP2-22 |
铜芯聚氯乙烯绝缘聚氯乙烯护套铜带屏蔽钢带铠装控制电缆 |
关键词：KVVRP-450/750V 7*2.5
