| | 品牌：华强牌 | | 型号：YCW-0.6/1KV-3*120+1*35电缆 | | 线芯材质：铜丝 | |
| | 电压等级：中.低压电力电缆（35千伏及以下） | | 绝缘材料：橡皮绝缘电力电缆 | | 芯数：3+1 | |
| | 护套材质：橡胶 | | 电线最大外径：55 mm | | 绝缘厚度：2.0 mm | |
| | 标称截面：120平方 mm2 | | 用途：橡胶电力电缆 | | | |
YCW-0.6/1KV-3*120+1*35电缆制造标准:GB5013.4-1997 JB8735.2-1998，本产品采用的标准与国际电工委员会IEC245(1994)的规定相一致.
YCW-0.6/1KV-3*120+1*35产品用途：本产品适用于交流额定电压450/750V及以下家用电器,电动工具和各种移动多电器设备.
电缆的长期工作温度应不超过65℃，电缆具有耐气候和一定的耐油性能,适用于在户外接触油污场合使用.
YCW-0.6/1KV-3*120+1*35电缆型号
| 型号 |
名称 |
用途 |
| YC、YCW |
重型橡套软电缆 |
用于各种移动电器设备，能承受较大的机械外力作用 |
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 3×1.5+1×1 |
9.4 |
12.0 |
--- |
--- |
13.3 |
13.7 |
14 |
| 3×2.5+1×1.5 |
11.0 |
14.0 |
282.7 |
305.6 |
7.98 |
8.21 |
19 |
| 3×4+1×2.5 |
13.0 |
16.0 |
406.8 |
435.7 |
4.95 |
5.09 |
26 |
| 3×6+1×4 |
14.5 |
19.5 |
600.1 |
640.34 |
3.30 |
3.39 |
33 |
| 3×10+1×6 |
20.5 |
26.5 |
925.1 |
990.9 |
1.91 |
1.95 |
47 |
| 3×16+1×6 |
23.0 |
26.5 |
1253.9 |
1341.5 |
1.91 |
1.95 |
62 |
| 3×16+1×10 |
23.0 |
30.0 |
--- |
--- |
1.21 |
1.24 |
63 |
| 3×25+1×10 |
28 |
35.5 |
1823.2 |
1941.5 |
0.780 |
0.795 |
83 |
| 3×35+1×10 |
30.0 |
38.5 |
1980.4 |
244.7 |
0.554 |
0.565 |
100 |
| 3×50+1×16 |
36.0 |
46.0 |
3952 |
3439.7 |
0.368 |
0.393 |
125 |
| 3×70+1×25 |
40.0 |
51.0 |
4504.4 |
4772.6 |
0.272 |
0.277 |
--- |
| 3×95+1×35 |
46.5 |
59.0 |
5972 |
6346 |
0.206 |
0.210 |
--- |
| 3×120+1×35 |
46.5 |
59.0 |
6362.1 |
6662.4 |
0.161 |
0.164 |
--- |
| 3×150+1×50 |
52.0 |
66.0 |
7889.3 |
8252.6 |
0.129 |
0.132 |
--- |
3+2芯
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 3×4+2×2.5 |
14.3 |
17.8 |
399 |
415 |
4.95 |
5.09 |
26 |
| 3×6+2×4 |
19.5 |
23.0 |
607 |
631 |
3.30 |
3.39 |
33 |
| 3×10+2×6 |
23.0 |
26.0 |
914 |
947 |
1.91 |
1.95 |
47 |
| 3×16+2×6 |
28.5 |
33.5 |
1194 |
1235 |
1.21 |
1.24 |
62 |
| 3×25+2×10 |
30.0 |
35.0 |
1697 |
1762 |
0.780 |
0.795 |
83 |
| 3×35+×10 |
36.0 |
41.0 |
2275 |
2350 |
0.554 |
0.565 |
100 |
| 3×50+2×16 |
40.0 |
45.0 |
3074 |
3117 |
0.386 |
0.393 |
125 |
| 3×50+2×25 |
42.5 |
45.5 |
3454 |
3564 |
|
|
|
| 3×70+2×25 |
44.0 |
50.0 |
4165 |
4285 |
0.272 |
0.272 |
--- |
| 3×95+2×35 |
46.0 |
52.5 |
5552 |
5270 |
0.206 |
0.10 |
--- |
| 3×120+2×35 |
52.0 |
58.0 |
6405 |
6550 |
0.161 |
0.164 |
--- |
| 3×150+2×50 |
61.0 |
67.0 |
8065 |
8376 |
0.129 |
0.132 |
--- |
| 3×185+2×50 |
78.0 |
86.0 |
9538 |
9891 |
0.106 |
0.108 |
--- |
| 3×240+2×70 |
81.0 |
89.0 |
12083 |
12580 |
0.0801 |
0.0817 |
--- |
| 3×150+2×70 |
62.5 |
66.0 |
8224 |
8394 |
|
|
|
4+1芯
芯数×标数
截面mm |
平均外径mm |
电缆计算重量
KG/KM |
20摄氏度时导电阻
Ω/km不大于 |
空气中敷设
允许载流量 |
| 下限 |
上限 |
YC |
YCW |
铜芯 |
镀锡铜芯 |
| 4×4+1×2.5 |
14.5 |
17.0 |
411 |
427 |
4.95 |
509 |
24 |
| 4×6+1×4 |
19.5 |
22.0 |
626 |
651 |
3.30 |
3.93 |
30 |
| 4×10+1×4 |
24 |
26.5 |
1081 |
1125 |
1.91 |
1.95 |
43 |
| 4×25+1×10 |
29.5 |
33.0 |
1983 |
2050 |
0.780 |
0.795 |
71 |
| 4×35+1×10 |
36.4 |
39.9 |
2582 |
2675 |
0.554 |
0.565 |
98 |
| 4×50+1×25 |
38.5 |
43.5 |
3525 |
3635 |
0.386 |
0.393 |
115 |
| 4×70+1×25 |
49.0 |
54.0 |
4730 |
4950 |
0.272 |
0.277 |
140 |
| 4×95+1×35 |
56.0 |
61.0 |
6353 |
6550 |
0.206 |
0.210 |
170 |
| 4×120+1×35 |
60.0 |
65.0 |
7674 |
7891 |
0.161 |
0.204 |
195 |
| 4×150+1×50 |
69.0 |
74.5 |
9375 |
9650 |
0.129 |
0.132 |
220 |
