| | 品牌：华强牌 | | 型号：ZRB-YJV22-5*4 | | 线芯材质：铜丝 | |
| | 电压等级：中.低压电力电缆（35千伏及以下） | | 绝缘材料：塑料绝缘电力电缆 | | 芯数：4芯 | |
| | 护套材质：聚氯乙烯 | | 电线*大外径：12 mm | | 绝缘厚度：1.2 mm | |
| | 标称截面：4平方 mm2 | | 用途：电力电缆 | | | |
ZRB-YJV22-5*4铠装电缆本产品适用于交流50HZ，额定电压0.6/1KV的线路中，供输配电能之用。
1．电缆导体的高额定温度为70℃。
2．短路时（长持续时间不超过5s）电缆导体的温度不超过60℃。
3．敷设电缆时的温度不低于0℃，弯曲半径应不小于电缆外径的10倍。
ZRB-YJV22-5*4铠装电缆型号、名称和使用范围
| VV22 |
聚氯乙烯绝缘钢带铠装聚氯乙烯护套电力电缆 |
敷设在室内，隧道及管道中，电缆不能承受压力和机械外力作用 |
| ZRB-YJV22 |
聚氯乙烯绝缘钢带铠装聚氯乙烯护套阻燃电力电缆 |
敷设在室内，隧道及直埋土壤中，电缆不能承受压力和其他外力作用 |
电缆结构尺寸VV22、ZRB-YJV220.6/1KV PVC绝缘PVC护套阻燃或非阻燃电力电缆
| 导体标称横截面(mm2) |
导体中单线根数 |
绝缘厚度(mm) |
钢带厚度(mm) |
外护套厚度(mm) |
电缆近似外径(mm) |
电缆近似重量(kg/km) |
20℃导体电阻≤( Ω/km) |
试验电压Kv/5min |
| Cu |
Al |
Cu |
Al |
| 1×10 |
7 |
1.0 |
2×0.2 |
1.4 |
13.6 |
384 |
265 |
1.83 |
3.02 |
3.5 |
| 1×16 |
7 |
1.0 |
2×0.2 |
1.4 |
14.6 |
432.0 |
331.0 |
1.15 |
1.91 |
3.5 |
| 1×25 |
7 |
1.2 |
2×0.2 |
1.4 |
16.4 |
574.0 |
415.0 |
0.727 |
1.20 |
3.5 |
| 1×35 |
7 |
1.2 |
2×0.2 |
1.5 |
17.5 |
699.0 |
478.0 |
0.524 |
0.868 |
3.5 |
| 1×50 |
19 |
1.4 |
2×0.2 |
1.5 |
19.3 |
870.0 |
569.0 |
0.387 |
0.641 |
3.5 |
| 1×70 |
19 |
1.4 |
2×0.2 |
1.6 |
21.1 |
1118.0 |
685.0 |
0.268 |
0.443 |
3.5 |
| 1×95 |
19 |
1.6 |
2×0.2 |
1.6 |
23.4 |
1444.0 |
844.0 |
0.193 |
0.320 |
3.5 |
| 1×120 |
37 |
1.6 |
2×0.2 |
1.7 |
25.0 |
1719.0 |
960.0 |
0.153 |
0.253 |
3.5 |
| 1×150 |
37 |
1.8 |
2×0.2 |
1.7 |
27.0 |
2046.0 |
113.0 |
0.124 |
0.206 |
3.5 |
| 1×185 |
37 |
2.0 |
2×0.2 |
1.8 |
30.7 |
2672.0 |
1503.0 |
0.0991 |
0.164 |
3.5 |
| 1×240 |
61 |
2.2 |
2×0.2 |
1.9 |
33.3 |
3353.0 |
1816.0 |
0.0754 |
0.125 |
3.5 |
| 1×300 |
61 |
2.4 |
2×0.5 |
2.0 |
36.4 |
4072.0 |
2145.0 |
0.0601 |
0.100 |
3.5 |
| 1×400 |
61 |
2.6 |
2×0.5 |
2.1 |
40.1 |
5033.0 |
2570.0 |
0.0470 |
0.0778 |
3.5 |
| 1×500 |
61 |
2.8 |
2×0.5 |
2.2 |
44.1 |
6277.0 |
3099.0 |
0.0366 |
0.0605 |
3.5 |
| 1×600 |
91 |
2.8 |
2×0.5 |
2.3 |
48.7 |
7746.0 |
3674.0 |
0.0283 |
0.0469 |
3.5 |
| 1×800 |
91 |
2.8 |
2×0.5 |
2.6 |
51.4 |
9075.0 |
4117.0 |
0.0221 |
0.0367 |
3.5 |
| 导体标称横截面(mm2) |
导体中单线根数 |
绝缘厚度(mm) |
钢带厚度(mm) |
外护套厚度(mm) |
电缆近似外径(mm) |
电缆近似重量(kg/km) |
20℃导体电阻≤( Ω/km) |
试验电压Kv/5min |
| Cu |
Al |
Cu |
Al |
| 4×4 |
1 |
1.0 |
2×0.2 |
1.8 |
18.5 |
565 |
464 |
4.61 |
7.41 |
3.5 |
| 4×6 |
1 |
1.0 |
2×0.2 |
1.8 |
19.7 |
685 |
533 |
3.08 |
4.61 |
3.5 |
| 4×10 |
7 |
1.0 |
2×0.2 |
1.8 |
22.8 |
960 |
699 |
1.83 |
3.02 |
3.5 |
| 4×16 |
7 |
1.0 |
2×0.2 |
1.8 |
25.3 |
1273 |
851 |
1.15 |
1.91 |
3.5 |
| 4×25 |
7 |
1.2 |
2×0.2 |
1.8 |
30.5 |
1998 |
1374 |
0.127 |
1.20 |
3.5 |
| 4×35 |
7 |
1.2 |
2×0.2 |
1.9 |
33.5 |
2505 |
1602 |
0.524 |
0.868 |
3.5 |
| 4×50 |
19 |
1.4 |
2×0.5 |
2.0 |
35.2 |
3122 |
1832 |
0.387 |
0.641 |
3.5 |
| 4×70 |
19 |
1.4 |
2×0.5 |
2.2 |
38.7 |
4025 |
2220 |
0.268 |
0.443 |
3.5 |
| 4×95 |
19 |
1.6 |
2×0.5 |
2.4 |
44.7 |
5291 |
2842 |
0.193 |
0.320 |
3.5 |
| 4×120 |
37 |
1.6 |
2×0.5 |
2.5 |
49.4 |
6464 |
3370 |
0.153 |
0.253 |
3.5 |
| 4×150 |
37 |
1.8 |
2×0.5 |
2.6 |
53.7 |
7866 |
3998 |
0.124 |
0.206 |
3.5 |
| 4×185 |
37 |
2.0 |
2×0.5 |
2.8 |
58.9 |
9452 |
4772 |
0.0991 |
0.164 |
3.5 |
| 4×240 |
61 |
2.2 |
2×0.5 |
3.0 |
61.0 |
11916 |
5727 |
0.0754 |
0.125 |
3.5 |
| 4×300 |
61 |
2.4 |
2×0.5 |
3.0 |
67.0 |
14118 |
6558 |
0.0601 |
0.100 |
3.5 |
| 4×400 |
61 |
2.4 |
2×0.5 |
3.4 |
73.6 |
19950 |
9366 |
0.0470 |
0.0778 |
3.5 |
